SYSTEM DIAGNOSTICS

7.1 - WM100 SIGNALS

If the WM100 has no wireless device acquired, it will flash red once per second;

otherwise it will flash as described under sections 7.1.1 and 7.1.2.

7.1.1 - Signals with control unit on stand-by

Flashes Meaning

1 red flash The interface is not combined with any device

1 green flash,

1 green flash

The interface is connected with at least one devi-

ce; the combined devices respond correctly; the

combined devices have a fully charged battery

1 red flash,

1 green flash

At least one of the combined devices has an

uncharged battery; the combined devices respond

correctly

1 green flash,

1 red flash

The combined devices have a fully charged battery;

in the previous maneuvers, at least one of the devi-

ces had communication problems

1 red flash,

1 red flash

At least one of the combined devices has an unchar-

ged battery; in the previous maneuvers, at least one

of the devices had communication problems

In all cases, the flashing is updated at the end of each manoeuvre or when the

control unit comes on again, after a period in stand-by.

Whenever flashing is updated, if there is an alarm situation (dead battery or poor

signal from one of the devices), WM100 (fig. 3) will make a “beep-beeeeep” type

sound.

7.1.2 - Signals during a manoeuvre/testing

During a manoeuvre (or when testing the system), the green led flashes continu-

ously and intermittently.
