Take a few moments to familiarize yourself with camera controls
and displays. You may find it helpful to bookmark this section
and refer to it as you read through the rest of the manual.
The Camera Body
Parts of the Camera
31 2 54
7
9
6
5
14
15
16
13 1112
17
8
18
10
1 Movie-record button .................. 46, 47
2 Shutter-release
button ..............................51, 57, 62, 66
3 Power switch........................................19
Power lamp ..........................................19
4 Mode dial ................................................ 6
5 Microphone
6 Focal plane mark (E)
7 AF-assist illuminator
Self-timer lamp....................................73
Red-eye reduction lamp ............ 75, 77
8 Flash pop-up button ..........................76
9 Eyelet for camera strap......................15
10 Connector cover
11 Lens release button............................18
12 Dust shield.................................105, 106
13 Lens mount ..........................................17
14 Mounting mark ...................................17
15 Body cap .............................................103
16 Built-in flash .........................................74
17 HDMI connector
18 USB connector...................................100
