Nikon ECLIPSE TE2000-E User Manual

I. Parts of the microscope and their names
14
4. Condensers
System condenser
When mounted on When mounted on T-DS dia-illuminator 30W
T-DH dia-illuminator 100W (Only for HMC observation.)
A: Condenser aperture diaphragm
B: Condenser module
C: Condenser module clamp screw
D: Condenser lens
(3 types available; ELWD, LWD, HMC)
E: Annular diaphragm centering screw
(on Ph modules only)
ELWD-S condenser SLWD condenser
A： Centering handle clamp screw
B： Centering handle
C： Turret
A
B
C
SLWD condenser can onl
y
be mounted on
T-DS dia-illuminator 30W.
