Nikon N Series/K Series Total Station Instruction Manual 33
Getting Started 3
Contrast adjustment window
When the 3-switch window is open, press
[<] or [>] to
display the contrast adjustment window. Then press
[^]
or
[v] to change the contrast level. The arrow indicates
the current contrast level. To return to the 3-switch
window, press
[<] or [>].
When you have finished changing display light and
sound settings, press
[ESC] to close the 3-switch or contrast adjustment window.
[DSP] key
Use the key to change the current display screen or to change display settings.
Switching between display screens
When several display screens are available, the
DSP
indicator appears at the top left of the screen, and the
screen indicator (for example,
1/4) appears at the top
right.
To move to the next available screen, press
[DSP].
For example, if the DSP2 screen is currently displayed,
press
[DSP] to move to the DSP3 screen. The screen
indicator changes from
2/4 to 3/4.
When the secondary distance unit is set, an additional screen is available. It
shows the HD, VD, and SD values. For information on setting the secondary
distance unit, see page 121.
The smallest unit of display for distances measured in feet-and-inches is 1/16
in. Smaller units are impractical in the field. When the actual value is greater
than 99999'11''15/16, the “>” symbol is shown. If the actual distance is less
than -9999'11''15/16, the “” (solid triangle) symbol is shown. This does not
affect calculations. The precise value is used internally in all cases.
