nilan Compact S Series User Manual

Subject to alterations Page 27 of 33
Datalog
The datalog interval is set via the menu SERVICE - DATALOG INTV at between 1 and 120
minutes.
If 0 / OFF is selected, logging is not periodical, but only on events and alarms.
• Temperatures are logged in Celsius, in whole degrees, in order to minimise the log file size.
• The status of digital inputs and outputs is combined in two shared log variables: ”Din” and
”Dout”.
HOTWATER
AIR
QUALITY
AIR
EXCHANGE
DEFROST
INLET
CONTROL
SERVICE
ENTER
TEMP.
CONTROL
PRESET
OFF
ROOM
KONTROL
RESTART
OFF
MANUAL
OFF
INLET
HEATING
Data increment
[1..120] minutes
MODBUS
ADR 30
DATALOG
INTV 10
Figur 22: The "Datalog" Menu
