KNOW YOUR MACHINE

As you read this manual, you will occasionally run across a bold number or letter in parentheses - example: (2). These numbers refer to an item shown on these

pages unless otherwise noted. Refer back to these pages whenever necessary to pinpoint the location of an item mentioned in the text. NOTE: Refer to the

service manual for detailed explanations of each item illustrated on the next 4 pages.

1 Recovery Tank Cover

2 Operator’s Seat (adjustable)

3 Drive Pedal, Directional/Speed

4 Drive and Steer Wheel

5 Rear Wheel

6 Battery Compartment

7 Waste Bin

8 Detergent Cartridge (EcoFlex models only)

9 Seat Prop Rod

10 Machine Battery Connector

11 Headlights (optional)
