8
⑦ To prevent external damage to the unit, do not install it near a road or track.
⑧ To avoid causing nuisance to neighbors, make sure the unit is installed in an area that is not
sensitive to noise.
⑨ Keep the unit out of the reach of children.
⑩ Installation space:
Unit: mm
Do not put anything less than 1500mm (5ft) in front of the heat pump.
Leave 500mm (2ft) of empty space on the sides and back of the heat pump and free space for
air circulation above
Do not leave any obstacles above or in front of the device!
3.3.4 Installation Layout
The installation diagram is shown in the following figure –
Pool → Pump → Filter → Heat Pump → Sanitizer → Return to Pool:
Notice: The filter must be cleaned regularly to ensure that water in the system is clean and to
avoid lack of water flow. It is necessary that a drainage valve is fixed at the lowest point in the
lower water pipe to completely drain water out of the system for winterizing. If the unit is not
To Next Page
