2.3. Main Parts of the Unit
Top cover
8
Front plate
15
Middle plate
Left handle
9
Fan motor cover
16
Pipe component
Motor support
10
Chassis
17
EEV
Left plate
11
Right plate
18
Fan motor
Fan blade
12
Wire controller
19
High efficiency finned heat exchanger
Fixed plate 1
13
Compressor
20
Electrical box
Fixed plate 2
14
Titanium heat exchanger
21
Back net
