Nirvana NE55 User Manual

5
2.4. SPECIFICATIONS
Model
NE55
Power supply(V/Ph/Hz)
208-230V~/60Hz
Rated Ambient Temp Range (°F)
23~104
1
Heating Capacity (Btu/h) – 80/80/80
55000
1
COP
6.0
2
Heating Capacity (Btu/h) - 50/63/80
35000
2
COP
4.0
Maximum Water Outlet Temp. (°F)
104
Rated Water Flow (gpm)
23.8
Rated Water Pressure Drop (psi)
3.77
Maximum Input Power (kBtu/h)
14.0
Fan Motor Rating Load (FLA) (A)
0.4
Fan Motor Horsepower (Hp)
1/8HP
Compressor Rated Load RLA (A)
15.7
Compressor Lock Rotor Amperage (LRA) (A)
86
Minimum Circuit Ampacity (A)
18.5
Breaker Size MIN/MAX (A)
20A/30A
Refrigerant Quantity (lbs)
R410A/3.417
Dry Weight (lbs)
134.5
Net Dimensions W×D×H (inches)
39.2×15.2×25.9
Water Pipe Connection
1.5 Inch Quick Connect
Water Proof Class
IPX4
Electricity Shock Proof Class
Ⅰ
Refrigerant Side Pressure Limits (psi)
638/217
Water Side Pressure Limits (psi)
100 psi
The technical specifications of our heat pumps are provided for information purposes only. We
reserve the right to make changes without notice.
