Nokia 445PRO User Manual

445N
15
2.3. Checking the Operation of PowerSaver
The proper operation of the function requires a computer with VESA DPMS power management
capabilities. Note that the power saving feature must be activated in the computer wh en checking
the operation.
State Colour of the power-- on indicator 5V Heater 12V Video
Normal Operation Green Yes Yes Yes Yes
Stand-- by Green Yes Yes Yes No
Suspend Green Yes Yes No No
Power Off Blinking Green Yes No No No
DPMS (Display Power Management Signaling) is a trade mark of Video Electronics Standard
Association (VESA)
