Nokia 6000 User Manual

13
Select a mode:
• Upgrade: installation of new software version
• Main code: upgrade of the system only, without erasing user data
• User DB: installation of the channel list
Upgrade File: select the le from USB storage.
Select Start and press OK to start the upgrade process. The message „Are you sure you want to upgrade?“ will
appear. If you agree, select „Yes“. The message „Burn ash! Do not turn o!“ will appear.
The progress bar shows 100% when nished and the device will restart automatically.
WARNING: After an update, the receiver restarts automatically. During the upgrade process please NEVER
disconnect the receiver from the mains or switch o the power! Doing so might damage your receiver and will
void warranty! Please note that the channel list and favorite lists will be overwritten.
6.4 USB backup
This feature allows you to back up the user DB (database) or settings to a USB storage.
User DB contains the channel lists (TV and radio channel lists) of a Nokia Terrestrial Receiver.
Preset contains the settings of a Nokia Terrestrial Receiver.
You can back up channel lists and settings on a USB device and transfer them to other Nokia Terrestrial
Receivers using the USB upgrade function.
Insert an external USB storage device, select “Backup mode” (User DB/ Preset) and “Start”. The screen will
show “Reading ash” - “Writing le” - “Backup is successful”.
NOTE:
1. We recommend that you use empty USB storage devices for the USB backup.
2. Please always make backups of data on your USB storage device before using it with the receiver.
3. StreamView cannot take responsibility for any loss of information or circumstances caused by loss of information.
4. During back up please never disconnect USB storage and the power supply.
6.5 Games
• Othello
• Tetris
7. Settings
7.1 Language
This menu allows you to set up your language preferences.
7.1.1 Language
Use
buttons to select the language for the OSD. Press OK to open a list to make selection faster.
7.1.2 First audio
The rst audio language follows OSD display by default. You can use buttons to change the audio language
as first priority, if available.
7.1.3 Second audio language
Use
buttons to select a language that will be played when the language selected as 1st audio language is
not available.

Nokia 6000 Specifications

Audio and Video

display resolution	HD TV
video resolution	1080i, 720p, 576i
audio decoding	Dolby Digital Plus

Ports & interfaces

antenna input	Yes
HDMI	Yes
USB 2.0	0.5 V, max. 500mA
AV	3.5 mm
digital audio	coaxial

Power

power supply	AC 100 - 240 V AC ~ 50/60 Hz
input voltage	DC 12 V, 1 A
power consumption working	max. 12 W
power consumption in standby	0.5 W

Operating Environment

operating temperature	0 ~ +50 °C
storage temperature	-20 ~ +70 °C

Weight and Dimensions

dimensions	112 x 123 x 24 mm
weight	0.23 kg
