Nokia 6230 Service Manual

nokia
CONNECTING PEOPLE
PAGE 19 (23)
CONFIDENTIAL
Approved 3.0
CMO Operations & Logistics
DJk
WW Service Solutions & Development
Bochum / Germany 24.01.2005
Service Manual 6230/i Level 1&2 Copyright © 2004-2005 Nokia Corporation. All rights reserved.
13. CAMERA GONOGO TEST
Before starting the GoNoGo test,
check that camera window is clean.
If not, clean the window with cloth.
o From Home Menu, press
the Menu key
o
To take a picture press the Menu key (Capture)
o This Image will be saved to Gallery into the Photos folder automatically.
o
Test was successful, if the Image appears on your Display. The camera is ok.
o Select Delete
o
Select Yes
o Select EXIT for Home Menu
o If the test is failed see Quick Trouble Shooter.

Nokia 6230 Specifications

General

Display Type	TFT, 65K colors
Resolution	128 x 128 pixels
Internal Memory	6 MB
Battery Type	Removable Li-Ion 850 mAh battery (BL-5C)
Stand-by	Up to 300 h
Talk time	Up to 5 h
Status	Discontinued
Network	GSM
2G bands	GSM 900 / 1800 / 1900
SIM	Mini-SIM
5-way navigation key	Yes
Downloadable wallpapers, screensavers	Yes
Video	Yes
Loudspeaker	Yes
3.5mm jack	No
WLAN	No
Infrared port	Yes
USB	Pop-Port
Messaging	SMS, MMS, Email, Instant Messaging
Browser	WAP 2.0/xHTML
Java	Yes, MIDP 2.0
Predictive text input	Yes
Organizer	Yes
Voice dial	Yes
Brand	Nokia
Weight	97 g (3.42 oz)
Display Size	1.5 inches
Card Slot	MMC
Main Camera	VGA
Announced	2003
GPRS	Class 10
Phonebook	1000 entries
Alert types	Vibration; Downloadable polyphonic ringtones
Games	Yes
Colors	Black
SAR	0.73 W/kg (head)
Dimensions	103 x 44 x 20 mm, 76 cc
Bluetooth	Yes, v1.1
Radio	FM radio
