GB 13
Antenna with one LNB for Sirius
When you select alternative 2 from the previous menu (above)
and press OK you will get the “Antenna adjustment” menu
shown to the right.
Three channels are preprogrammed. When you adjust the an-
tenna towards Sirius these channels will be used to locate the
Sirius satellite.
1 Select one of the preprogrammed channels. Adjust the an-
tenna towards the Sirius satellite until the AGC *
)
level get as
high as possible. The level is indicated with the red bar at the
top of the menu.
2 When the antenna is aimed at the satellite and the signal level
is as high as possible, press OK.
Antenna/Satellite Selection
ISelect the alternative on the first line when you have anantenna
equipped with one (1) LNB and intend to receive channels from
the Sirius satellite. To acheive best possible reception you should
use a Universal LNB.
Select line 2 for other antenna and satellite combinations.
FIRST TIME INSTALLATION
3 The bar at the top of the menu will now change to a red/yel-
low/green Signal Quality (SNR) *
)
indicator for that specific
channel.
If you have found a digital signal from Sirius the background
will change and show a TV picture. It may take a few seconds be-
fore the picture appears.
If you do not get a picture, you may be tuned to an analogue sig-
nal source. Another reason could also be that the antenna is po-
sitioned towards the wrong satellite.
If so, press the BACK button and start from point 1 again.
(If you have a good indication in the signal quality menu, but no
picture from any of the channel alternatives, try proceeding with
the channel search anyway by pressing OK).
When you have picture from a TV channel, press OK. The Media-
master automatically starts searching for channels from the sat-
ellite. When the search procedure is finished you will get a mes-
sage telling how many TV- and radio channels have beed found.
Please refer to page 16.
*
)
Information about AGC and SNR is found on the next page.
OK
OK
To Next Page
