Loading Paper> 20
M
ULTI
PURPOSE
TRAY
1. Open the multi purpose tray and press gently down on the
paper platform (1) to ensure it is latched down.
2. Load the paper and adjust the paper guides (2) to the size
of paper being used.
• When printing on headed paper load the paper into the
multi purpose tray with pre-printed side up and top
edge into the printer.
• Envelopes should be loaded face up with top edge to
the left and short edge into the printer.
• Do not exceed the paper capacity of about 50 sheets or
10 envelopes. Maximum stacking depth is 10mm.
3. Press the tray latch button (3) inwards to release the
paper platform, so that the paper is lifted and gripped in
place.
Set the correct paper size for the multi purpose tray in the Media
Menu. (See “Printer functions (User Settings)” on page 40.)
2
1
3
To Next Page
