Olympus Aloka ProSound F75 User Manual

Doppler modes
FLOW displays directional colour doppler (velocity scale)
eFLOW displays directional power doppler (signal strength scale)
at high sensitivity for detecting small vessels
Press ENTER to toggle between full-line and dashed doppler box,
and trackball to adjust size and location (respectively)
MULTI-GAIN dial adjusts the brightness of the doppler signal
PW displays the pulse at a defined point
Use the trackball and SELECT to select point of interest on left B
Mode image
1
2
3
4
1
2
3
4
5
5
6
6
eFLOW
PW
Aloka Prosound F75 Quick Reference Guide
