12
EN
Loading the card
3
Compact Flash
Open the card cover (1, 2).
Insert the SD/SDHC/SDXC card (referred to
as “card” in these instructions) until it locks in
place (3) .
Open the card cover (1, 2).
Insert the CF card (referred to as
“
card
”
in these
instructions) into the slot as far as it can go (
3
).
Card cover
CF card slot
Front side
Eject button
Removing the card
Never open the card cover while the card
access lamp is blinking.
• Press the eject button all the way in to
make it pop out.
• Pull out the card.
• Press the inserted card lightly and it will be
ejected.
• Pull out the card.
SD Card
Compact Flash
Card access lamp
SD Card
Card access lamp
Connector
2
1
2
1
SD Card slot
3
• Turn off the camera before loading or removing the card.
• The power is turned off if you load or remove the card with the power on.
