Olympus E-M10 Mark IV User Manual

Shooting
2
88 EN
Movie quality Movie quality components
1280×720 Normal 30p
Choose the desired combination of frame size,
bit rate, and frame rate.
1 2
3
1 Frame size
4K : 3840×2160
FHD : 1920×1080
HD : 1280×720
2 Bit rate (compression ratio)*
1
SF (Super Fine), F (Fine), N (Normal)
3 Frame rate
30p (60p), 25p (50p), 24p
1920×1080 Super Fine 50p
1920×1080 Super Fine 25p
1280×720 Super Fine 25p
1920×1080 Fine 50p
1920×1080 Fine 25p
1280×720 Fine 25p
1920×1080 Normal 50p
1920×1080 Normal 25p
1280×720 Normal 25p
1920×1080 Super Fine 24p
1280×720 Super Fine 24p
1920×1080 Fine 24p
1280×720 Fine 24p
1920×1080 Normal 24p
1280×720 Normal 24p
*1 The bit rate can not be changed when the frame size is [4K].

Olympus E-M10 Mark IV Specifications

General

Sensor Type	Live MOS
Effective Pixels	20.3 megapixels
Image Stabilization	5-axis in-body image stabilization
Viewfinder Resolution	2.36 million dots
Viewfinder Coverage	Approx. 100%
Screen Type	Tilting touchscreen LCD
Screen Resolution	1.04 million dots
Battery Type	BLS-50 lithium-ion battery
Connectivity	Wi-Fi, Bluetooth
Built-in Flash	Yes
External Flash	Hot shoe
Image Processor	TruePic VIII
Sensor Size	17.3 x 13.0 mm
Autofocus System	121-point contrast-detection AF
Viewfinder Type	Electronic
Viewfinder Magnification	Approx. 1.23x
Continuous Shooting Speed	Up to 15 fps
Video Recording	4K UHD at 30p
Shutter Speed	1/4000 to 60 sec
Battery Life	Approx. 360 shots
Dimensions	121.7 x 84.6 x 49 mm
Weight	383 g (with battery and memory card)
Storage	SD/SDHC/SDXC
ISO Sensitivity	ISO 200 - 25600 (expandable to 100 - 25600)
