ILLUMINATION UNITS
24
170 (Distance to the light axis)
Convex section(2-4) for positioning
3.5
Less than R6
21
82 (Revolving nosepiece relief dimension)
5
5.5
(6)
(11)
2.5
52 (Revolving nosepiece relief dimension)
100 (±0.1)
62 (±0.1)
37 ±0.1 (45° location face)
Location face
Location face
2
45° (±10')
4-M5 depth12 or more
36 (±0.1)
MOUNTING DIMENSIONS OF ILLUMINATORS (BX-RLA2, BX-URA2 and BX-KMA/BX-KMA-ESD)
Unit: mmFix illuminator using four M5 screws and projection for fastening.
Reflected light illuminators for BF
BX-KMA/BX-KMA-ESD
Enables brightfield, Nomarski DIC and simple polarizing observations. ESD model is also available.
Weight: 3.1kg
Unit: mm
* Combine SZX-TLGAD when using fiber illumination.
88
ø70
108
Cable length 260.5mm
312.5
250
30
84
3.5
41
Illuminator
mounting
position
Revolving
nosepiece
mounting
position
Unit name Description Weight (g)
U-25LBD LBD filter slider 20
U-25IF550 IF550 filter slider 20
U-25ND6 ND filter 20
U-25ND25 ND filter 20
U-25FR Frost filter slider 20
U-25L42 UV-cut filter 20
U-PO3 Polarizer slider for reflected light 71
U-POTP3 Polarizer slider for reflected light 71
with tint plate
U-AN360-3 360° rotatable analyzer slider 79
U-AN Analyzer slider for reflected light 50
U-DICR DIC slider for reflected light 130
U-DICRH DIC slider for reflected light 130
(high resolution type)
U-DICRHC DIC slider for reflected light 130
(high contrast type)
Accessories
