Olympus Microscope User Manual

DEEP ULTRAVIOLET OBSERVATION SYSTEM
42
Deep ultraviolet observation system
This module adds a deep ultraviolet (248nm) optical system to a general microscope.
An ultra-high resolution observation is executed by using an extremely short wavelength ray.
Unit: mm
108
258.5
69
79
ø8 (light guide)
3430.4
105.8
2000
+200
0
or 5000
+200
0
(39.5)6 5.5
ø70
196.8
196
ø30
ø39.4
1-32 UNF
(C Mount Thread)
45
(distance between
mounting positions)
102.5
U-UVF248IM
UV248 compatible intermediate tube
U-UVF2FB/5FB
UV quartz light guide
U-UVF248LB+U-LH80HGXE
UV248 compatible light source box + Mercury Xenon lamp housing
8170
227
41240
210.3
4-ø4.5, ø8 C'bore 5 Deep
4-ø4.5, ø13 C'bore 5 Deep
150
15045
18030
170
157.5
20
Weight: 1.9kg
Weight:6.5kg
Weight: U-UVF2FB 50g
U-UVF5FB 80g
