Video camera port
This port can be attached directly to the trinocular observation tube as well as to the single port tube with lens.
VIDEO CAMERA ADAPTERS
37
U-TV1x-2
Video port 1x
22
ø60
28
ø64
Video camera mount adapters
Allows attachment to video cameras with C, Bayonet, Sony and F mounts.
Use with the U-TV1x-2. Focus by amount of screwing into U-TV1x-2.
Unit: mm
Unit: mm
U-CMAD3
C-mount adapter
U-BMAD
Bayonet mount adapter
U-TMAD
T mount adapter
U-FMT
F/T mount adapter *
U-SMAD
Sony mount adapter
Weight: 70g Weight: 30g
* It must be combined with U-TMAD
Image plane
plane
M56X2
49
ø42
ø64
48
30
3
ø64
ø48
60
38
40 4
Image plane
M56X2
17.53
M56X2
1-32UN
ø30
ø44.5
ø64.4
80.5
60.5
48.7
20
4
Image plane
4
23
43
ø64
ø42
M42X0.75
M56X2
55
ø54.7
ø45.7
13
46.5
Image plane
Weight: 165g Weight: 80g Weight: 90g
Weight: 150g
