OBSERVATION TUBES
117.223
61.981 139.400
88.000
2.837
70.330
149.081
20° 0' 0"
42° 0' 0"
95.929
101.929
318.527
328.338
337.718
72.200
Super widefield trinocular observation tubes
Trinocular observation tubes with super widefield of view. Compatible with F.N. 26.5.
55.6
79.6
180.8
49.968.6
98.8
173.8
220.8
82.3*
63.1
14
U-SWTR-3
Super widefield trinocular tube
MX-SWETTR
Super widefield erect image tilting trinocular tube
U-SWETR
Super widefield erect image trinocular tube
U-SWTR-3 26.5 24 50-76 100/0, 20/80, 0/100 Inverted 2300
U-SWETR 26.5 24 50-76 100/0, 0/100 Erect 4200
MX-SWETTR 26.5 0-42 50-76 100/0, 0/100 Erect 4200
Unit: mm
Field Number
(F.N.)
Inclination angle
(degree)
Interpupillary distance
(mm)
Name
Light path selector
(eyepiece/video port)
Observation image
Weight
(g)
*Length marked with an asterisk (*) may vary according to interpupillary distance. The distance for figure shown is 62mm.
73
83.4
92.9
6298.6
201.9
248.9
76.4*
2241936.5
