SZX7
14
SPECIFICATIONS
Item Specifications
1. Zoom microscope body.
· SZX-ZB7
Zoom magnification variation: Left/right optical axis parallel method.
Zoom drive: Horizontal knob system.
Click stop for each zoom magnification: ON-OFF switching possible.
Zoom ratio values: 7 values (0.8X to 5.6X)
Zoom magnification indication: 0.8, 1, 1.25, 1.6, 2, 2.5, 3.2, 4, 5, 5.6
Objective mounting: Screw mounting into thread.
Aperture iris diaphragm control: Possible using the AS unit (SZX-AS).
2. Observation tube
· SZX-BI45
· SZX-TBI
· SZX-TR30
Interpupillary distance adjustment range: 50 to 76 mm
Eyepiece clamping knobs provided.
Eyepieces: WHSZ series eyepieces.
3. Standard stand
· SZ2-ST
Rack-and-pinion using ball guide.
Knob rotation tension adjustable.
Focusing stroke 120 mm.
Stage plate: Diameter 100 mm.
Oblique illumination system (LSGA) mountable.
Transmitted light illumination stand (SZ2-ILA) mountable.
4. Objectives
*The SZ2-ET auxiliary sleeve is required
when the SZ2-ST is used.
Model Working Distance
DFPL0.5X-4 171 mm*
DFPL0.75X-4 116 mm
DFPLAPO1X-4 81 mm
SZX-ACH1X 90 mm
SZX-ACH1.25X 68 mm
DFPL1.5X-4 45.5 mm
DFPL2X-4 33.5 mm
5. Eyepieces
*An eyepiece micrometer disk with a
diameter of 24 mm and thickness of
1.5 mm can be inserted.
The disk area outside the field
number is invisible.
WHSZ10X FN 22
* WHSZ10X-H FN 22, with diopter adjustment ring
* WHSZ15X-H FN 16, with diopter adjustment ring
WHSZ20X FN 12.5
* WHSZ20X-H FN 12.5, with diopter adjustment ring
* WHSZ30X-H FN 7, with diopter adjustment ring
6. Operating environment · Indoor use
· Altitude: Max. 2000 m
· Ambient temperature: 5° to 40°C (41° to 104°F)
· Maximum relative humidity:80% for temperatures up to 31°C (88°F), decreasing
linearly through 70% at 34°C (93°F), 60% at 37°C
(99°F), to 50% relative humidity at 40°C (104°F)
SZX-TR30
Trinocular tube
Tilting angle: 30°
Light path selection: 2
steps
Binocular 100%, TV &
Photo 80%/Binocular
20%
SZX-BI45 SZX-TBI
Binocular tube Tilting binocular tube
Tilting angle: 45° Tilting angle: 5° to 45°
