ISSUE4 2-7 Troubleshooting
ëÊ2èÕ Troubleshooting
2. Error Codes
2-1 Error-code list
Display location and error codes
Error Identification Remarks
Monopolar cut
output-setting
indicator
Monopolar
coagulation output-
setting indicator
— 01 Patient-plate problem
• Patient-plate cord is discon-
nected.
• Improper patient-plate connec-
tion
• Patient plate is disconnected.
—02
Solution detection
problem
• Output occurred without the use
of saline
• Output occurred when the elec-
trode was not immersed in saline.
• Active cord (for saline) is discon-
nected.
• Active cord (for saline) is broken.
—04
Output timing prob-
lem
Output for more than 60 sec
(Only during monopolar or saline
mode)
—08
Output-switch prob-
lem
• Output level set to 0 W
• Output switch damaged
• Power was supplied while the
output switch was pressed.
—10
Output-switch ON
problem
Multiple switches of the foot switch
or handpiece were simultaneously
pressed.
—20
Short-circuit of
setting switch
• Power was supplied while the
front-panel switches were
pressed.
• A front-panel switch is damaged.
01 —
High-frequency
current-monitor dam-
age
02 —
High-frequency volt-
age-monitor damage
04 —
Waveform-circuit
damage
08 —
Converter (power
supply)-1 damage
Overcurrent signal (converter)
10 —
Converter (power
supply)-2 damage
Overvoltage signal (converter)
20 —
Converter (power
supply)-3 damage
Temperature problem signal (con-
verter)
40 —
Patient-plate circuit
damage
