Omron H5CR series User Manual

H5CR H5CR
8
Two mounting clips help the soft plastic cover Y92A-48F1 fit
snugly over the front of the timer to protect against dirt and
water. Timer settings can be changed when the cover is on.
The cover is intended for use in areas where unusual service
conditions do not exist.
Y92A-48F1 Soft plastic cover
50.5
(1.99)
Y92A-48T Terminal cover
47.2
(1.86)
The terminal cover protects wiring connections on the
Standard and Short Body models.
Connections
■ TERMINAL ARRANGEMENT
H5CR-L (Economy)
SIGNAL
RESET
0 V
TIMED
SOURCE
Contact output
Contact output
H5CR-S (Short body)
H5CR-B (Standard)
KEY/P
SIGNAL
RESET
0 V
5 A
250 VAC
TIMED
SOURCE
Contact output
RESET
GATE
KEY/P
SIGNAL
TIMED
GATE
0 V
0 V
SIGNAL
TIMED
SOURCE
RESET
KEY/P
GATE
SIGNAL
RESET
5 A
250 VAC
TIMED
RESET
GATE
KEY/P
SIGNAL
TIMED
UNUSED
SOURCE
Transistor outputTransistor output
Transistor output
H5CR-SS
H5CR-BS
H5CR-LS
Note: Do not connect unused terminals.
0 V
5 A
250 VAC
0 V
UNUSED
UNUSED
50.5
(1.99)
47.2
(1.86)
