112 LD Cart Transporter User's Manual 14766-000 Rev H
7.1 Touchscreen
Figure 7-2. Screen Initialization Status Display
After initialization, either the Choose Dropoff or Patrol Route screen will be displayed.
Touchscreen Configuration
The behavior of the touchscreen is highly configurable. See Configuring a Touchscreen on page
68.
Screen Top Bar
The top of the screen shows basic AMR information. This includes a bar graph indicating the
WiFi signal strength, the name of the AMR, and the battery state of charge. If the AMR is con-
nected to an Enterprise Manager, it will also be specified here.
Left Screen Pane
The screen logo is displayed in the upper part of the left pane. This doesn’t change, regardless
of the mode you are in. See Screen Logo on page 72.
Below the screen logo, the AMR status is displayed, first graphically, and below that, in text.
