4 Optics and Lighting
4-4
MicroHAWK F320-F / F330-F / F420-F / F430-F Smart Camera User Manual
4-2 MicroHAWK Illumination
F420-F and F430-F Inner LEDs: 4 white, 4 red (625 nm nominal).
F420-F and F430-F Outer LEDs: 8 high-output white or red (617 nm nominal).
F420-F and F430-F have both inner and outer LEDs. Options are also available for IR and blue outer LEDs.
F320-F and F330-F only have inner LEDs.
4-2-1 LED Modules
Description Left P/N Right P/N LED P/N Wavelength
Expansion, Red 43-9500055-01 43-9500056-01 LA E65F-CAEB-24-1 617 nm
Expansion, White 43-9500055-02 43-9500056-02 NFSW036BLT b3-b6/P9-P12 N/A
Expansion, IR 43-9500055-03 43-9500056-03 SFH 4259S 850 nm
Expansion, Blue 43-9500055-04 43-9500056-04 LB E63C-T2V2-35-34 469 nm
F430-F
F420-F
F430-F with
Ring Light
Option
F320-F
F330-F
