Omron NJ Series Troubleshooting Manual

3 Error Tables
3-74
NJ-series Troubleshooting Manual (W503)
3-1-4 Errors in the EtherNet/IP Function Module
Built-in EtherNet/IP Port on CPU Unit
Event code Event name Meaning Assumed cause
Level
Reference
Maj Prt Min Obs Info
04200000 hex Communica-
tions Control-
ler Failure
A hardware error
was detected in the
communications
controller of the
built-in EtherNet/IP
port.
• Communications Controller
hardware error
S NJ-series
CPU Unit
Built-in Ether-
Net/IP Port
User’s Manual
(Cat. No.
W506)
14200000 hex MAC
Address
Error
The MAC address
in non-volatile
memory was not
read correctly.
• Non-volatile memory failure S Same as
above.
14220000 hex EtherNet/IP
Processing
Error
A fatal error was
detected in the Eth-
erNet/IP Function
Module.
• Hardware has failed. S Same as
above.
34210000 hex Basic Ether-
net Setting
Error
An error was
detected in the
Ethernet settings.
• Setting error
• Power was interrupted when a
download was in progress for
the Ethernet basic settings.
• Memory error
S Same as
above.
34220000 hex TCP/IP Basic
Setting Error
(Local Port IP
Address)
An error was
detected in the IP
address settings.
• Setting error
• Power was interrupted when a
download was in progress for
the TCP/IP basic settings.
• Memory error
• The IP address acquired from
BOOTP server is illegal.
S Same as
above.
84010000 hex IP Address
Duplication
Error
The same IP
address is used
more than once.
• The IP address of the built-in
EtherNet/IP port is also used as
the IP address of another node.
S Same as
above.
84020000 hex BOOTP
Server Con-
nection Error
Connection with the
BOOTP server
failed.
• Server setting error
• Server is down.
• An error occurred in the com-
munications path.
S Same as
above.
14210000 hex Identity Error The CIP identity
information in non-
volatile memory
was not read cor-
rectly.
• Non-volatile memory failure S Same as
above.
34200000 hex Tag Data Link
Setting Error
An error w
as
detected
in the
communications
settings for tag data
links.
• Power was interrupted when a
download was in progress for
the data link settings.
• Memory error
S Same as
above.
34230000 hex TCP/IP
Advanced
Setting Error
(IP Router
Table)
An error was
detected in the
hosts in the IP
router table.
• Setting error
• Power was interrupted when a
download was in progress for
the TCP/IP advanced settings.
• Memory error
• There is a mistake in the IP
router table settings or hosts
settings.
S Same as
above.
