m
1
: Type of memory table
0(30
H
): Character-string memory table
1(31
H
): numeral table
d
1
d
2
d
3
: Copy source memory table address (see table below)
s
1
s
2
s
3
: Copy destination memory table address (see table below)
Model Character-string
memory table address
Numeral table address
NT20M, NT2000M 000 to 031 (3-digit BCD) 000 to 127 (3-digit BCD)
NT600M 000 to 255 (3-digit BCD) 000 to 255 (3-digit BCD)
Description Copies the contents of the copy source memory table to the copy destination
memory table. The memory table contents are copied to a memory table of the
same type: character-string memory table to character-string memory table or
numeral table to numeral table.
5-1-7 Lamp and Touch Switch Display (Bit Specification)
Format
1B
[ESC]
4B
K
m0
1
m0
2
m1
2
m2
1
m2
2
m3
1
m1
1
m3
2
OD
[CR]
m0 to m3: Specification of lamps and touch switches (2-digit hexadecimal)
The correspondence of the lamp and touch switch numbers to the
bit representation in m0 to m3 is shown in the following table.
Parameter
mx
1
mx
2
7 6 5 4 3 2 1 0
m0 07 06 05 04 03 02 01 00
m1 15 14 13 12 11 10 09 08
m2 23 22 21 20 19 18 17 16
m3 31 30 29 28 27 26 25 24
Bit ON: Lamp or touch switch lights (or flashes)
Bit OFF: Lamp or touch switch does not light (flash)
Example
To light lamps and touch switch numbers 1, 5, 6, 7, and 26,
m0
1
,m0
2
,m1
1
,m1
2
,m2
1
,m2
2
,m3
1
,m3
2
= E2000004
Description Changes the lamp or touch switch lighting status.
The Support Tool sets if the lamp corresponding to a bit lights continuously or
flashes.
5-1-8 Lamp and Touch Switch Display (Address Specification)
Format
1B
[ESC]
n
1
n
2
m
1
51
Q
m
1
: Display status
m
1
NT20M, NT2000M, NT600M
0(30
H
) Not lit (normal display)
1(31
H
) Lit
2(32
H
) Flashing inverse (lamps)
Lit (touch switches)
3(33
H
) All not lit
%
Section 5-1
