18
2. Installation and connection
(2) Install the unit.
● Do not install the unit in any position other than those indicated below.
2-2 Installation and connection (BY50FW)
Connection to back up your computer and peripherals
Write the usage start date on the label on the top side. Also, by using the included UPS
monitoring software, possible to keep a record of usage start date by the software.
(1) Disconnect all AC input plugs of your computer and peripherals from a wall outlet (commercial power).
Note
Before installing this device, make a record of the serial number of this device.
The serial number is required when contacting us about the device.
The serial number is written in the label on the unit.
Horizontal BY50FW
Vertical BY50FW
(Attach the included stand so
that the left side is the bottom.)
• Detach the rubber feet from the
bottom surface (both at the front
and rear) when positioning
vertically.
• Once the rubber feet are removed,
protrusions on the bottom surface
will become visible.
Align the stand with these
protrusions to attach it.
Remove the rubber feet
and attach the stand.
Computer
Modem or other
peripheral
Wall outlet
(commercial power)
To Next Page
