Omron R88D-1SN20F-ECT User Manual

2 - 19
2 Models and External Dimensions
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
2-3 Model Tables
2
2-3-4 Decelerator Model Tables
The following tables list the Decelerator models for 1S-series Servomotors.
The standard shaft type is a straight shaft. A model with a key and tap is indicated with “J” at  of the
Decelerator model number in the following table. Select an appropriate model based on the Servomotor
rated output.
 For 3,000-r/min Servomotors
2-3-4 Decelerator Model Tables
Backlash: 3 Arcminutes Max.
Specifications
Model Reference
Servomotor
rated output
Reduction
ratio
50 W 1/21 R88G-HPG14A21100B P. 2-102
1/33 R88G-HPG14A33050B
1/45 R88G-HPG14A45050B
100 W 1/5 R88G-HPG11B05100B
1/11 R88G-HPG14A11100B
1/21 R88G-HPG14A21100B
1/33 R88G-HPG20A33100B
1/45 R88G-HPG20A45100B
200 W 1/5 R88G-HPG14A05200B
1/11 R88G-HPG14A11200B
1/21 R88G-HPG20A21200B
1/33 R88G-HPG20A33200B
1/45 R88G-HPG20A45200B
400 W 1/5 R88G-HPG14A05400B P. 2-104
1/11 R88G-HPG20A11400B
1/21 R88G-HPG20A21400B
1/33 R88G-HPG32A33400B
1/45 R88G-HPG32A45400B
750 W (200 V) 1/5 R88G-HPG20A05750B
1/11 R88G-HPG20A11750B
1/21 R88G-HPG32A21750B
1/33 R88G-HPG32A33750B
1/45 R88G-HPG32A45750B
750 W (400 V) 1/5 R88G-HPG32A052K0B
1/11 R88G-HPG32A112K0B
1/21 R88G-HPG32A211K5B
1/33 R88G-HPG32A33600SB
1/45 R88G-HPG50A451K5B
