2 - 25
2 Models and External Dimensions
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
2-3 Model Tables
2
2-3-6 Cable and Connector Model Tables
The following tables list the models of cables, shield clamp and connectors. The cables include encoder
cables, motor power cables, and brake cables.
2-3-6 Cable and Connector Model Tables
Encoder Cables (Standard Cable)
Applicable Servomotor Model
100 V
200 V
3,000-r/min Servomotors of 50 W, 100 W,
200 W, 400 W, and 750 W
3 m R88A-CR1A003C
5 m R88A-CR1A005C
10 m R88A-CR1A010C
15 m R88A-CR1A015C
20 m R88A-CR1A020C
30 m R88A-CR1A030C
40 m R88A-CR1A040C
50 m R88A-CR1A050C
200V
400V
200V
3,000-r/min Servomotors of 1 kW to 3 kW
2,000-r/min Servomotors
1,000-r/min Servomotors
400V
3,000-r/min Servomotors of 3 kW or less
2,000-r/min Servomotors
1,000-r/min Servomotors
3 m R88A-CR1B003N
5 m R88A-CR1B005N
10 m R88A-CR1B010N
15 m R88A-CR1B015N
20 m R88A-CR1B020N
30 m R88A-CR1B030N
40 m R88A-CR1B040N
50 m R88A-CR1B050N
200 V
400 V
3,000-r/min Servomotors of 4 kW or more
1,500-r/min Servomotors
3 m R88A-CR1B003V
5 m R88A-CR1B005V
10 m R88A-CR1B010V
15 m R88A-CR1B015V
20 m R88A-CR1B020V
30 m R88A-CR1B030V
40 m R88A-CR1B040V
50 m R88A-CR1B050V
