Onkyo DV-CP701 Service Manual

DV-CP701
IC BLOCK DIAGRAM/ TERMINAL DESCRIPTION
-
+
-
+
1
2
3
4
8
7
6
5
(Top view)
Pin description
1. A OUTPUT
2. A -INPUT
3. A +INPUT
4. V-
5. B +INPUT
6. B -INPUT
7. B OUTPUT
8. V+
Q403,Q404,Q405,Q406 NJM4580M-D (2-ch Ope. amp.)
