DV-CP701
PART REPLACEMENT-2
<Mounting>
Tray panel
1-4-4. Insert the tray panel.
1-4-5. Set the FFC (P707) to mechanism control PC board assy.
1-4-6. The pin of main gear and fiting the position of the
slot on the tray.
1-4-7. Pull up the nail on the tray panel and insert the tray.
