EXPLODED VIEW PARTS LIST
!: Safety part
REF. NO. PART NAME DESCRIPTION PART NO.
A01 Front Panel
<B>
1466-1801-0
A01 Front Panel
<S>
1466-1802-0
A02 KNOB (STBY)
<B>
2446-3901-0
A02 KNOB (STBY)
<S>
2446-3701-0
A03 KNOB (SEL)
<B>
2446-4101-0
A03 KNOB (SEL)
<S>
2446-3801-0
A04 KNOB (EJECT)
<B>
2446-4601-0
A04 KNOB (EJECT)
<S>
2446-4401-0
A05 KNOB (PLAY)
<B>
2446-4301-0
A05 KNOB (PLAY)
<S>
2446-4001-0
A06 KNOB (DISPLAY)
<B>
2446-4501-0
A06 KNOB (DISPLAY)
<S>
2446-4201-0
A07 Retainer (BDG) 4135-3701-0
A08 Badge
<B>
28135244
A08 Badge
<S>
28135245
A12 Clear Plate
<B>
3716-8411-0
A12 Clear Plate
<S>
3716-8211-0
A13 Facet (LIGHT) 3716-8306-0
A14 Facet (S) 3716-8511-0
A15 Spacer 27270437
A18 Front Bracket (F) 4135-3181-0
A19 Tapping Screw 2.6TTB+8B(BC) 838426088
A21 Isolation Sheet 4154-6191-0
A22 Plastic Rivet P-3055B-BL 880048
A25 Tapping Screw 3TTB+8B 838130088
A26 Tapping-tighten screw with washer 3TTW+8B(BC) 831430088
A30 Chassis 1404-7601-0
A31 Holder KGLS-10RF 27190428A
A32 Clamper CLAMP WS-2W 27300243
A33 Retainer (R) 4135-3191-0
A41 Foot LEG 27175316C
A42 Cushion 4157-0311-0
A46 Cushion 4149-0401-0
A48 Cord Bushing S-RELIEF #2271 27300750
A50 Tray Panel
<B>
4154-6121-0
A50 Tray Panel
<S>
4154-6122-0
A53 Rear Panel
<BMDD>
1404-7501-0
A53 Rear Panel
<BMPA>
1404-7502-0
A53 Rear Panel
<SMDD>
1404-7501-0
A54 Tapping Screw 3TTB+8B(BC) 838430088
A56 Label (DVD2) 3000-9443-0
A58 Label (ROM) 29362727
A59 Cushion 28141541
A214 Top Cover 1404-7401-0
A215 Tapping Screw
3TTB+8B
BC
<B>
838430088
A215 Tapping Screw
3TTB+8B
UN
<S>
838930088
E102 Wire tie 260259
E821 Ferrite Core GM8T25*15*10 1808-0740-0
F001 Fuse
1.6A-UL/T-237 <MDD>
252158
F001 or Fuse
1.6A-T/UL-ST2 <MDD>
252252
F001 Fuse
2.5A-SE-EAK FUSE <MPA>
252075
F001 or Fuse
2.5A-SE-TL250V <MPA>
252275
P1001 FFC NCFCD-26003 7012-6553-0
P1101 Connector assy NSAS-12P0960 20022391210UL
P2001 FFC NCFC5-141522 7012-6525-0
P2401 FFC NCFC5-152022 7012-6526-0
P2501 Connector assy NSAS-14P1093 7012-6527-0
P2901 Connector assy NSAS-12P1105 7012-6528-0
P702 Connector assy NSAS-22P1141 7012-6521-0
