42
En
Explanatory Notes
Main Menu Input/Output Assign
Monitor Out
You can specify the output resolution for the HDMI OUT
and COMPONENT VIDEO MONITOR OUT and have
the AV receiver upconvert the picture resolution as neces-
sary to match the resolution supported by your TV.
■ Resolution
` Through
:
Select this to pass video through the AV receiver at
the same resolution and with no conversion.
` Auto:
Select this to have the AV receiver automatically
convert video at resolutions not supported by your
TV.
` 480p:
Select this for 480p output and video conversion as
necessary.
` 720p:
Select this for 720p output and video conversion as
necessary.
` 1080i:
Select this for 1080i output and video conversion as
necessary.
` 1080p:
Select this for 1080p output and video conversion as
necessary.
HDMI Input
If you connect a video component to an HDMI input, you
must assign that input to an input selector. For example, if
you connect your Blu-ray Disc/DVD player to HDMI
IN 2, you must assign “HDMI2” to the “BD/DVD” input
selector.
If you’ve connected your TV to the AV receiver with an
HDMI cable, composite video, S-video and component
video sources can be upconverted
*
and output by the
HDMI OUT. You can set this for each input selector by
selecting the “-----” option.
Here are the default assignments.
■ BD/DVD, VCR/DVR, CBL/SAT, GAME, PC,
TV/CD, PHONO, PORT
` HDMI1, HDMI2, HDMI3, HDMI4, HDMI5:
Select the HDMI IN to which the video component
has been connected.
` -----:
Output composite video, S-Video, and component
video sources from the HDMI OUT. The video out-
put signal from the HDMI OUT is the one config-
ured in “Component Video Input” (➔ 43).
•“AUX” is used only for input from the front panel.
• Each HDMI input cannot be assigned to two input selec-
tors or more. When HDMI1 - HDMI5 have already
been assigned, you must set first any unused input selec-
tors to “-----” or you will be unable to assign HDMI1
- HDMI5 to input selector.
Input/Output Assign
a Menu selection
b Setting target
c Setting options (default setting underlined)
Main menu Speaker Setup
■ Subwoofer
` Ye s
:
Select if a subwoofer is connected.
` No:
Select if no subwoofer is connected.
a
b
c
Input selector Default assignment
BD/DVD HDMI1
VCR/DVR HDMI2
CBL/SAT HDMI3
GAME HDMI4
PC HDMI5
AUX FRONT (Fixed)
TUNER ----- (Fixed)
TV/CD -----
PHONO -----
PORT -----
IN
OUT
Composite video, S-Video,
component video
Composite video, S-Video,
component video
HDMI
HDMI
