Speaker Installation
5.1 Channel System
a
b
12
34
5
6
a: 22° to 30°, b: 120°
This is a basic 5.1 Channel System. Front speakers output the front stereo
sound, and a center speaker outputs the sound of the center of the screen,
such as dialogs and vocals. Surround speakers create the back sound eld.
Subwoofer reproduces the bass sound, and creates the rich sound eld.
The front speakers should be positioned at ear height while the surround
speakers should be positioned just above ear height. The center speaker should
be set up facing the listening position at an angle. Placing the subwoofer between
the center speaker and the front speaker gives you a natural sound even when
playing music sources.
1,2 Front Speakers
3,4 Surround Speakers
5 Center Speaker
6 Subwoofer
❏ Speaker Layouts and Selectable Listening
Modes ( p52)
