Onkyo HT-S3910 User Manual

71
Front Panel≫ Rear Panel≫ Remote≫
Contents
≫
Connections
≫
Playback
≫
Setup
≫
2. Speaker
 1. Conguration
Change the settings of connection environment of the speakers.
Setting Item Default Value Setting Details
Speaker
Channels
5.1 ch Select "2.1 ch", "3.1 ch", "4.1 ch", "5.1 ch",
"2.1.2 ch" or "3.1.2 ch" to suit the number of
speaker channels connected.
Subwoofer Yes Set whether a subwoofer is connected or not.
"Yes": When a subwoofer is connected
"No": When a subwoofer is not connected
Height Speaker Top Middle Set the speaker type if height speakers are
connected to the SURROUND or HEIGHT
terminals.
Select "Top Middle", "Dolby Speaker (Front)" or
"Front High" according to the type and layout of the
connected speakers.
• If the item cannot be selected even though
connection is correct, check if the setting in
"Speaker Channels" matches the number of
connected channels.
Speaker
Impedance
6 ohms or above Set the impedance (Ω) of the connected speakers.
"4 ohms": When any of the connected speakers
have 4 Ω or more to less than 6 Ω impedance
"6 ohms or above": When the connected speakers
all have 6 Ω or more impedance
• For impedance, check the indications on the
back of the speakers or their instruction manual.
 2. Crossover
Change the settings of crossover frequencies.
Setting Item Default Value Setting Details
Front 150 Hz Select the crossover frequency from "40 Hz" to
"200 Hz" to start outputting frequencies for each
channel.
"Full Band": Full band will be output.
• If "Conguration" - "Subwoofer" is set to "No",
"Front" is xed to "Full Band", and the low
pitched range of the other channels is output
from the front speakers. Refer to the instruction
manual of your speakers to make the setting.
Center 150 Hz Select the crossover frequency from "40 Hz" to
"200 Hz" to start outputting frequencies for each
channel.
"Full Band": Full band will be output.
• "Full Band" can be selected only when "Front" is
set to "Full Band".
• If the item cannot be selected even though
connection is correct, check if the setting in
"Conguration" - "Speaker Channels" matches
the number of connected channels.
Height 150 Hz Select the crossover frequency from "40 Hz" to
"200 Hz" to start outputting frequencies for each
channel.
"Full Band": Full band will be output.
• "Full Band" can be selected only when "Front" is
set to "Full Band".
• If the item cannot be selected even though
connection is correct, check if the setting in
"Conguration" - "Speaker Channels" matches
the number of connected channels.

Onkyo HT-S3910 Specifications

General

Disc types supported	No
Optical disc player type	Not included
3D	Yes
Video formats supported	-
Audio decoders	DTS:X, Dolby Atmos
RMS rated power	155 W
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	109 dB
Total Harmonic Distortion (THD)	10 %
AM band range	522 - 1611 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	40
Front speaker type	2-way
Front speaker impedance	6 Ω
Front speakers RMS power	150 W
Front speaker frequency range	80 - 20000 Hz
Front speaker woofer diameter (imperial)	3 \
Satellite speaker frequency range	80 - 2000 Hz
Subwoofer frequency range	28 - 5000 Hz
Subwoofer driver diameter (imperial)	6.3 \
Product color	Black
HDMI in	4
SCART ports quantity	0
Number of HDMI outputs	1
Package depth	435 mm
Package width	535 mm
Package height	675 mm
Package weight	19000 g
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.2 W
Power consumption (typical)	445 W

Weight and Dimensions

Subwoofer weight	4600 g
Center speaker weight	600 g
Subwoofer dimensions (WxDxH)	230 x 331 x 389 mm
Front speaker dimensions (WxDxH)	98.5 x 106 x 140.5 mm
Center speaker dimensions (WxDxH)	244 x 102 x 96 mm
