TX-RZ800(B)MDC
<Note>
Parts marked by "NSP" are generally unavailable because <Notes>
they are not in our Master Spare Parts List. (B) : Black color model
<MDC> : 120V
Canadian/USA/(Mexico) model
: NSP
TX-RZ800(B)MDC
EXPLODED VIEW PARTS LIST
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
D6925 DIODE LN25XB60 1 22380345
Q6050 TRANSISTOR TTC0001(Q_T)TO3PN 1 2204130
Q6051 TRANSISTOR TTC0001(Q_T)TO3PN 1 2204130
Q6052 TRANSISTOR TTC0001(Q_T)TO3PN 1 2204130
Q6053 TRANSISTOR TTC0001(Q_T)TO3PN 1 2204130
Q6054 TRANSISTOR TTC0001(Q_T)TO3PN 1 2204130
Q6055 TRANSISTOR TTC0001(Q_T)TO3PN 1 2204130
Q6056 TRANSISTOR TTC0001(Q_T)TO3PN 1 2204130
Q6060 TRANSISTOR TTA0001(Q_T)TO3PN 1 2204120
Q6061 TRANSISTOR TTA0001(Q_T)TO3PN 1 2204120
Q6062 TRANSISTOR TTA0001(Q_T)TO3PN 1 2204120
Q6063 TRANSISTOR TTA0001(Q_T)TO3PN 1 2204120
Q6064 TRANSISTOR TTA0001(Q_T)TO3PN 1 2204120
Q6065 TRANSISTOR TTA0001(Q_T)TO3PN 1 2204120
Q6066 TRANSISTOR TTA0001(Q_T)TO3PN 1 2204120
[CHASSIS SCREW]
A103 BOTTOM LEG (FRONT) 2 27175477A N
A105 BOTTOM LEG (REAR) 2 27175478A N
A107 CUSHION (CORK)D25 x 9 x T2 4 28141968 N
A143 PLATE (FAN) 1 27262850C
A221 LABEL (PT)ONK 1 29392650
A251 REAR PANEL TXRZ800DC 1 27124675 N
A253 LABEL (SP) 1 29392874
A255 LABEL (SP2) 1 29392875
A301A LABEL (E-CON) { 1} 29364978
[CABINET]
A401 FRONT BRACKET (B) 1 27111630D N
A412 BACK PLATE 1 28133428
A413 PLATE (DOOR)(B) 1 27262928A N
A421 KNOB (CUR)AS BLACK 1 28326994C
A422 KNOB (ENTER) BLK 1 28326990
A423 KNOB (5)(B) 2 28327225 N
A426 PLATE (VOL) 1 27262931A N
A431 CLEAR PLATE 1 28192456 N
A440 KNOB (PURE) 1 28327208 N
A442 KNOB (STBY)(B) 1 28327234
A442 or KNOB (STBY)(B) ( 1) 28326904
A443 KNOB (1)(B) 2 28327209 N
A444 FACET 1 28198905
A445 BADGE 1 28135317
A446 KNOB (INP-C)(B) 1 28327213B N
A447 KNOB (INP-L)(B) 1 28327215A N
A448 KNOB (INP-R)(B) 1 28327216A N
A455 FRONT PANEL TXRZ800(B)MD 1 27213784B N
A461 DOOR (B) 1 28148858 N
A470 PLASTIC RIVET P3035B 2 880016
A480 KNOB (TONE)(B)AS 1 28327232 N
A481 KNOB (TONE)(B)AS 1 28327232 N
A482 KNOB (VOL)AS(B) 1 28327219 N
A701 COVER (B)808 (Bent) 1 28210071
A701 COVER (B)808 (Not Bent) 1 28210071Z
A731 LABEL (CAUTION) 1 29392531
[TRANS COIL]
T901 POWER TRANSFORMER NPT-1653D 1 2302125 !
[SW TRM]
F6901 FUSE 15A-TUL-250V 1 252303GR !
F6902 FUSE 15A-TUL-250V 1 252303GR !
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH
PART

Onkyo TX-RZ900 Specifications

General

Impedance	16 Ω
Receiver type	Surround
Frequency range	5 - 100000 Hz
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	106 dB
Total Harmonic Distortion (THD)	0.08 %
Dynamic power per channel (3 Ohm)	320 W
Dynamic power per channel (4 Ohm)	270 W
Dynamic power per channel (8 Ohm)	160 W
Power output per channel (20-20KHz@8 Ohm)	235 W
HDMI in	8
AC (power) in	Yes
Remote (IR) input	1
Composite video in	3
Component video (YPbPr/YCbCr) in	2
AM band range	522 - 1710 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Optical drive included	-
Display	LCD
Product color	Black
Audio decoders	DTS
Apple docking compatibility	iPad, iPhone, iPod
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.2 W
Power consumption (typical)	95 W
THX-certified	THX Select2 Plus
Package weight	21500 g

Weight and Dimensions

Depth	433.5 mm
Width	435 mm
Height	201.5 mm
Weight	18000 g
