Orion RKS400F-S User Manual

51
External dimensions
■RKS400F-S
Decrease the setting
Power cord access hole(φ30)
（Temperature，Alarm）
control plate
Hot air outlet
(M10 female screw)
With diaphragmed grommet
Hot air outlet
Hot air outlet
ＳＥＴ
ＯＮ
ＯＦＦ
ＲＥＳＥＴ ＡＬＡＲＭ
℃
ＣＯＯＬＥＲ
Detailed drawing of
ＳＥＴ
ＯＮ
ＯＦＦ
ＲＥＳＥＴ
ＡＬＡＲＭ
℃
ＣＯＯＬＥＲ
Cooler operatio
n lamp
Cooler ON/OFF switch Se
t switch
Digital Display
Increase the setting
Control plate
Drain port
Priming water port
Reset switch
8287
325
86 220
36187
222(left)
52 270(right)
155175
28.5 397
385
375
32
51
23
51
4
3
454
242
67 320
55
76
92 150
Water Inlet(Rp3/4)
Filter
Hot air outlet
Hot air outlet
Handle
φ11 hole
2-φ11 hole
Air suction
Water outlet(Rp3/4)
( Unit:mm )
