Installation and Operation Manual - 2000
ENGLISH
APPENDIX 4: DECORATIVE PANELS INSTALLATION
1. Start by fixing the front part of the decorative panel (A) in the two clips (C) welded on the sides
of the fire box.
2. Then, fix the back of the decorative side with three screws (B) supplied. Line up the decorative
sides parallel to the side of the appliance.
B
A
C
