palintest Lumiso Chlorine User Manual

Using Check Standards
Why is Percentage Transmission of Light being measured
with Lumiso Check Standards?
Lumiso works by measuring the amount of light that passes
through the sample. This value is known as the “Percentage
Transmission” or “%T”. Lumiso’s software then converts this
%T value into a concentration, such as mg/L of chlorine.
So, to verify that the instrument is within calibration it is only
necessary to check that the instrument correctly measures
%T for each wavelength of light it uses. This simplifies the
process for using check standards.
Check Standards can be purchased separately for your
Lumiso instrument. These standards contain Neutral
Density Filters (NDFs) and can be used to verify that the
instrument is within calibration
and performing correctly.
LMC001 LMC001
LMC001 LMC001
LMC005D
Blank
nm
5
3
0
LMC005D
B
nm
5
3
0
LMC005D
A
nm
5
3
0
LMC005D
C
nm
5
3
0
16

palintest Lumiso Chlorine Specifications

General

Instrument	Single wavelength, direct-reading colorimeter
Optics	LED light source optical system with narrow band wavelength filters and photodetectors
Test Cells	25 mm diameter tubes
Wavelengths	Automatic wavelength selection of 530 nm
Wavelength Tolerance	± 2 nm
Filter Bandwidth	5 nm
Blank/Zero setting	Held in memory, but instrument will prompt for re-blanking after 50 minutes
LCD Display	226 x 138 pixel with adjustable backlight
Results Log	50 results, with date, time and label
Operating Conditions	0 – 50°C 90% Relative Humidity (non-condensing)
Waterproof Rating	IP67 (Waterproof)
Power Supply	3 x 1.5V AA batteries USB Port 6V max, 200mA max (DC)
USB Port	Micro USB Type B

Weight and Dimensions

Size	163 x 70 x 45 mm
Weight	275g (including batteries)
