16 Replacement Parts List (Indoor Unit)
<Model: CS-A7DKD / CS-A9DKD / CS-A12DKD >
REF. NO. PART NAME & DESCRIPTION QTY. CS-A7DKD CS-A9DKD CS-A12DKD REMARKS
1 CHASSY COMPLETE 1 CWD50C1377 ← ←
2 FAN MOTOR 1 CWA921181 CWA921324 CWA921181 0
3 CROSS FLOW FAN COMPLETE 1 CWH02C1031 ← ←
4 BEARING ASS’Y 1 CWH64K007 ← ←
5 SCREW - CROSS FLOW FAN 1 CWH4580304 ← ←
6 EVAPORATOR 1 CWB30C1600 CWB30C1687 CWB30C1601
7 FLARE NUT 1 CWT25078(1/4”) ← ←
8 FLARE NUT 1 CWT25005 (3/8”)
←
CWT25007 (1/2”)
9 INTAKE AIR SENSOR COMPLETE 1 CWH32143 ← ←
10 DISCHARGE GRILLE COMPLETE 1 CWE20C2366 ← ←
11 VERTICAL VANE 9 CWE241150 ← ←
12 CONNECTING BAR 1 CWE261066 ← ←
13 CONNECTING BAR 1 CWE261070
← ←
14 AIR SWING MOTOR 1 CWA98260 ← ← 0
15 LEAD WIRE - AIR SWING MOTOR 1 CWA67C3977
← ←
16 CAP - DRAIN TRAY 1 CWH521096 ← ←
17 HORIZONTAL VANE 1 CWE241173
← ←
18 BACK COVER CHASSIS 1 CWD932454 ← ←
19 CONTROL BOARD CASING 1 CWH102259
← ←
20 TERMINAL BOARD COMPLETE 1 CWA28C2074 ← CWA28C2071 0
21 POWER SUPPLY CORD 1 CWA20C2159
← ←
22 ELECTRONIC CONTROLLER - MAIN 1 CWA743557 CWA743508 CWA743558 0
23 SENSOR COMPLETE 1 CWA50C2122
← ←
0
24 CONTROL BOARD FRONT COVER 1 CWH131207 ← ←
25 INDICATOR COMPLETE 1 CWE39C1115 ← ← 0
26 INDICATOR HOLDER 1 CWD932429 ← ←
27 INDICATOR HOLDER 1 CWD932430 ← ←
28 CONTROL BOARD COVER COMPLETE 1 CWH13C1120
← ←
29 REMOTE CONTROL COMPLETE 1 CWA75C2604 ← ← 0
30 FRONT GRILLE COMPLETE 1 CWE11C3125
← ←
31 INTAKE GRILLE COMPLETE 1 CWE22C1154
← ←
32 GRILLE DOOR 1 CWE141073
← ←
33 AIR FILTER 2 CWD001144
← ←
34 SCREW - FRONT GRILLE 2 XTN4+16C
← ←
35 CAP - FRONT GRILLE 2 CWH521109
← ←
36 DRAIN HOSE 1 CWH851063
← ←
37 INSTALLATION PLATE 1 CWH361067
← ←
38 BAG COMPLETE - INSTALLATION SCREW 1 CWH82C067 ← ←
39 FULCRUM 1 CWH621046 ← ←
40 ELECTRONIC CONTROLLER - IONIZER 1 CWA743675 ← ← 0
41 CASING - IONIZER 1 CWD932464
← ←
42 CASING - IONIZER 1 CWD932431 ← ←
43 ION GENERATOR 1 CWH94C0001
← ←
44 SUPERSONIC AIR PURIFYING DEVICE 1 CWH91C1013
← ←
45 ELECTRONIC CONTROLLER - SUPERSONIC 1 CWA743874
← ←
0
46 SUPER ALLERU BUSTER FILTER 1 CWD00C1133
← ←
47 FRAME FR AIR FILTER SUPERSONIC 1 CWD011026
← ←
48 FRAME FR AIR FILTER SUPERSONIC 1 CWD011027
← ←
(Note)
• All parts are supplied from PHAAM, Malaysia (Vendor Code: 061).
• “O” marked parts are recommended to be kept in stock.
74
CS-A7DKD CU-A7DKD / CS-A9DKD CU-A9DKD / CS-A12DKD CU-A12DKD /
