<Model: CU-A12DKD>
REF. NO. PART NAME & DESCRIPTION QTY. CU-A12DKD REMARKS
1 CHASSY ASS’Y 1 CWD50K2074
2 SOUND PROOF MATERIAL 1 CWG302110
3 FAN MOTOR BRACKET 1 CWD541030
4 SCREW - FAN MOTOR BRACKET 2 CWH551059
5 FAN MOTOR 1 CWA951117 0
6 SCREW - FAN MOTOR MOUNT 3 CWH55406
7 PROPELLER FAN ASS’Y 1 CWH03K1006
8 NUT - PROPELLER FAN 1 CWH56053
9 COMPRESSOR 1 2KS206D5AF04 0
10 ANTI - VIBRATION BUSHING 3 CWH50055 0
11 NUT - COMPRESSOR MOUNT 3 CWH4582065
12 CONDENSER 1 CWB32C1266
13 4-WAY VALVE 1 CWB00003
14 STRAINER 1 CWB11025
15 HOLDER COUPLING ASS’Y 1 CWH351023
16 2-WAY VALVE (LIQUID) 1 CWB021117 0
17 3-WAY VALVE (GAS) 1 CWB011148 0
18 TERMINAL COVER 1 CWH171012
19 NUT - TERMINAL COVER 1 CWH7080300
20 SOUND PROOF BOARD 1 CWH151023
21 CONTROL BOARD 1 CWH102102
22 TERMINAL BOARD ASS’Y 1 CWA28C2170 0
23 CAPACITOR - COMPRESSOR 1 DS371356CPNA 0
24 HOLDER CAPACITOR 1 CWH30057
25 CAPACITOR - FAN MOTOR 1 DS441205NPQA 0
26 CABINET SIDE PLATE (L) 1 CWE041031A
27 CABINET SIDE PLATE (R) 1 CWE041037A
28 CABINET FRONT PLATE 1 CWE06K1034
29 WIRE NET 1 CWD04C1009
30 CABINET TOP PLATE 1 CWE031014A
31 PLATE - C.B. COVER 1 CWH131088
32 CONTROL BOARD COVER 1 CWH13C1065
33 V-COIL COMPLETE 1 CWA43C2054
34 ELECTRO MAGNETIC SWITCH 1 CWA00059
35 ELECTROLYTIC CAPACITOR 1 CWA32C067
36 ELECTRO MAGNETIC SWITCH 1 K6A2C7A00002 0
37 L. TUBE 1 CWH5850080
38 TUBE ASS’Y (CHECK VALVE/ CAPILLARY) 1 CWT01C2640
39 PACKING - L. TUBE 1 CWB81012
40 OPERATING INSTRUCTIONS 1 CWH564479
41 INSTALLATION INSTRUCTIONS 1 CWF612620
42 INSTALLATION INSTRUCTIONS 1 CWF612681
42 INSTALLATION INSTRUCTIONS 1 CWF612738
(Note)
• All parts are supplied from PHAAM, Malaysia (Vendor Code: 061).
• “O” marked parts are recommended to be kept in stock.
78
CS-A7DKD CU-A7DKD / CS-A9DKD CU-A9DKD / CS-A12DKD CU-A12DKD /
