Panasonic CS-F50DB4E5 Service Manual

122
13.3.2. Heating Performance
HC: Heating Capacity IPT: Heating Power Consumption
Model Heating capacities are based on conditions
CS-F24DB4E5 Single phase, 50Hz 230V
Heating capacity Indoor temp. 20°C D.B.
7.1kW Outdoor temp. 7°C D.B. 6°C W.B.
Standard air volume 18 m
3
/min
Ambient Temperature Air Entering Condenser (°C D.B.)
Return -6°C0°C6°C12°C
Air HCHCHCHC
D.B. kW kW kW kW
15 5.18 6.21 7.46 8.66
20 4.90 5.86 7.10 8.52
25 4.62 5.54 6.75 8.17
Ambient Temperature Air Entering Condenser (°C D.B.)
Return -6°C0°C6°C12°C
Air IPT IPT IPT IPT
D.B. kW kW kW kW
15 1.65 1.89 2.24 2.64
20 1.75 2.01 2.36 2.74
25 1.84 2.12 2.48 2.80
