147
17 Replacement Part List (Outdoor Unit)
All parts are supplied from PHAAM, Malaysia (Vendor Code: 061)
NO. PART DESCRIPTION QTY PART NO.
1 FRONT GRILLE-COMPLETE 1 CWE11C3104
2 FRAME-FRONT GRILLE CO. 1 CWE11C3101
4 A.S MOTOR DC, SINGLE 12V 250 OHM 2 CWA981105
5 BRACKET-A.S.MOTOR 2 CWD932391
6 VANE 4 CWE241146
7 SHAFT 6 CWH631038
8 SHAFT 2 CWH631039
9 CONNECTOR-SHAFT 4 CWH081007
10 BEARING 6 CWH641008
11 LEAD WIRE-A.S.MOTOR 1 CWA67C5117
12 PLATE COVER FOR A.S.MOTOR 1 CWD911395
13 PLATE COVER FOR CONNECTING SHAFT 2 CWD911396
14 PLATE COVER FOR END SHAFT 1 CWD911397
21 L-PIECE 2 CWD701033
22 SIDE COVER FOR FRONT GRILLE CO. 4 CWD911398
24 INTAKE GRILLE 1 CWE221122
28 LEVER ARM 2 CWH651029
29 AIR FILTER 1 CWD001130
To Next Page
