15
3.7. CS-F50DB4E5 CU-B50DBE8
1. Cooling capacities are based on indoor temperature of 27°C D.B. (80.6°F D.B.), 19.0°C W.B. (66.2°F W.B.) and outdoor air
temperature of 35°C D.B. (95°F D.B.), 24°C W.B. (75.2°F W.B.)
2. Heating capacities are based on indoor temperature of 20°C D.B. (68°F D.B.) and outdoor air temperature of 7°C D.B. (44.6°F
D.B.), 6°C W.B. (42.8°F W.B.)
ELECTRICAL DATA (50 Hz)
ITEM / MODEL Indoor Unit Outdoor Unit
Main Body CS-F50DB4E5 CU-B50DBE8
Panel CZ-BT03P
Remote
Control
CZ-RD513C (Wired)
CZ-RL513B (Wireless)
Cooling Capacity kW 13.5
BTU/h 46,000
Heating Capacity kW 15.00
BTU/h 51,100
Refrigerant Charge-less m 30
Standard Air Volume for High
m
3
/min
32 96
cfm 1130 3387
Outside Dimension (H x W x D) mm 288 x 840 x 840 1170 x 900 x 320
inch 11-5/16 x 33-1/24 x 33-1/24 46-1/16 x 35-7/16 x 12-19/32
Net Weight kg (lbs) 28.5 (63) 102 (225)
Piping
Connection
Refrigerant Gas mm (inch) O.D Ø 15.88 (5/8) Flared Type
Liquid mm (inch) O.D Ø 9.52 (3/8) Flared Type
Drain
Compressor Type, Number of Set - Hermetic, 1
Starting Method - Permanent Split Capacitor
Motor Type - 2-pole 1 phase brushless motor
Rated Output kW - 4.50
Fan Type, Number of Set Turbo fan-1 Propeller fan-2
Motor Type 8-pole DC motor 6-pole single phase induction motor
Rated Output kW 0.06 0.07 x 2
Air-heat Exchanger (Row x Stage x FPI) Louver-fin type (2 x 12 x 21) Corrugate-fin type (2 x 44 x 20)
Refrigerant Control - Expansion Valve
Refrigerant Oil (Charged)
cm
3
- DAPHNE FV68D (1500)
Refrigerant (Charged) R410A kg (oz) - 3.40 (120)
Running Adjust-
ment
Control Switch Wireless or Wired Remote Control -
Room Temperature Thermostat -
Noise Level dB (A) Cooling: 47/42 56/-
Heating: 47/42 57/-
Power Level
dB
Cooling: 62/57 70/-
Heating: 62/57 71/-
Moisture Removal L/h (Pt/h) 8.6 (18.1)
EER W/W 2.69/2.67/2.62
COP W/W 3.07/3.04/3.01
ITEM / MODEL Condition by ISO5151
Volts V 380 400 415
Phase Three Three Three
Power Consumption kW Cooling 5.01 5.06 5.15
Heating 4.88 4.93 4.98
Running Current A Cooling 8.3 8.5 8.7
Heating 7.8 8 8.2
Starting Current A 55 58 61
Power Factor % Cooling 92 86 82
Heating 95 89 84
*Power Factor means total figure of compressor, indoor fan motor and outdoor fan motor.
Panasonic Power source AC, 3~380V,400V, 415V 50Hz
To Next Page
