Panasonic EP1015 User Manual

10
HOW TO USE
TO START/STOP MASSAGE ACTION
LEG MASSAGER OPERATION
Before using, first read all the instructions including the warnings and safety and operating precautions, as
well as the section on programmed and manual massage.
1. To operate the massager, press the “on/off” button.
• Check to be sure that the operation indicator lamp is lit.
2. To stop the massager during operation, press the “on/off”
button.
The massage heads will go up, spread out and stop in their
resting position.
• Check to be sure that the operation indicator lamp goes
out.
• With the heads in their resting position, you can sit com-
fortably, using the massager as a regular lounge chair.
• To resume the massage, press the “on/off” button. The
massage action or programmed massage course will
start from the beginning.
• Be sure to store the controller in the pocket on the side of
the left armrest when not in use.
1. Press the leg massage “on/off” button to turn on the leg
massager.
• Check to be sure that the operation indicator lamp on the
leg massage on/off button is lit.
2. To turn off the leg massager, press this leg massage on/off
button again.
Automatic timer for leg massager
• To prevent continuous operation of the leg massager, there is a built-in timer that will automatically turn
off the leg massager after 30 minutes of operation.
on
off
on
off
quick
stop
leg massage
reclining
1
3
5
neck
roller
position
Operation
indicator lamp
Leg massage
button
on
off
on
off
quick
stop
leg massage
reclining
1
3
5
neck
roller
position
Quick stop button
If you wish to stop the massage immediately, press the “quick stop”
button.
The massage heads will stop where they are.
• Check to be sure that the operation indicator lamp goes out.
• To resume the massage, press the “on/off” button. The massage
action or programmed massage course will start from the
beginning.
• To return the massage heads to the resting position, press the
on/off button, wait, then press it again. The massage heads will
then stop in a retracted resting position more comfortable for sitting.
Automatic timer for massage lounger
• To prevent excessive massage, there is a built-in timer which, after approximately 15 minutes of
operation, will automatically return the massage heads to their resting position and stop their motion.
• Turning on the on/off button while the massage heads are moving to their resting position will reset the
time for another 15 minutes (approximately).
• If the programmed massage button is pressed, the unit will stop after finishing the program.
on
off
on
off
quick
stop
leg massage
reclining
1
3
5
neck
roller
position
Quick stop
button

Panasonic EP1015 Specifications

Power

power source	120 V AC, 60 Hz
power consumption	200 W

Massage Specifications

kneading speed	Approx. 28 times/min.
tapping speed	Approx. 500 times/min. (per side)
rolling massage speed	Approx. 1 cycle every 37 sec.
massage width	Shoulder / lower back section: Approx. 2 15/16 in. (75 mm)
back rolling width/tapping width	Narrow: Approx. 3 5/16 in. (85 mm), Wide: Approx. 4 5/16 in. (110 mm)
massage heads up/down travel	Approx. 23 5/8 in. (600 mm)
regional back rolling	Automatic repetition within approx. 4 3/4 in. (120 mm) range
intensity adjustment	Adjusts massage head protrusion steplessly within approx. 1 3/4 in. (45 mm) range
shoulder position adjustment	5 steps
automatic shut-off	Approx. 15 min.

Weight and Dimensions

dimensions (H x W x D) not reclined with legrest lowered	41 11/32 x 34 41/64 x 40 35/64 in. (1050 x 880 x 1030 mm)
dimensions (H x W x D) reclined with legrest extended	29 9/64 x 34 41/64 x 68 7/64 in. (740 x 880 x 1730 mm)
reclining angle	Approx. 123° to 160°
weight	121 lbs. (55 kg)
maximum user weight	264 lbs. (120 kg)
