Panasonic EP1015 User Manual

Caster
6
GROUNDING INSTRUCTIONS
• This product must be grounded. If it should malfunction, grounding provides the path of
least resistance for electric current to reduce the risk of electric shock.
• This product is equipped with a cord having an equipment-grounding conductor and a
grounding plug. The plug must be plugged into an appropriate outlet that is properly
installed and grounded in accordance with all local codes and ordinances.
DANGER
• Improper connection of the equipment-grounding conductor can result in a risk of electric
shock. Check with a qualified electrician if you are in doubt as to whether the product is
properly grounded. Do not modify the plug provided with the product even if it does not fit
the outlet. Have a proper outlet installed by a qualified electrician.
• This product is for use on a nominal 120-volt
circuit and has a grounding plug that looks like
the plug shown in Figure A. Make sure that the
product is connected to an outlet having the
same configuration as the plug. No adaptor
should be used with this product.
HOW TO MOVE THE CHAIR
CAUTION
Do not move the chair while someone is sitting in it.
Failure to observe this point may cause the chair to tip over, possibly resulting in personal
injury.
Use the casters to move the chair.
• Do not attempt to move the chair by lifting from the front (right illustration). The correct way
to move the chair is by putting your foot on the caster and pushing down from behind the
chair (left illustration).
• It is easier to move the chair if the massage heads have been moved to their resting
positions and the backrest reclined.
• Moving the chair may damage easily marked floor surfaces; therefore, place a mat or
cloth on the floor and move the chair slowly.
• Before pushing down the chair, prepare yourself for its weight and exercise caution when
moving it.
GROUNDED
OUTLET
GROUNDING
PIN
Figure A
CORRECT WRONG

Panasonic EP1015 Specifications

Power

power source	120 V AC, 60 Hz
power consumption	200 W

Massage Specifications

kneading speed	Approx. 28 times/min.
tapping speed	Approx. 500 times/min. (per side)
rolling massage speed	Approx. 1 cycle every 37 sec.
massage width	Shoulder / lower back section: Approx. 2 15/16 in. (75 mm)
back rolling width/tapping width	Narrow: Approx. 3 5/16 in. (85 mm), Wide: Approx. 4 5/16 in. (110 mm)
massage heads up/down travel	Approx. 23 5/8 in. (600 mm)
regional back rolling	Automatic repetition within approx. 4 3/4 in. (120 mm) range
intensity adjustment	Adjusts massage head protrusion steplessly within approx. 1 3/4 in. (45 mm) range
shoulder position adjustment	5 steps
automatic shut-off	Approx. 15 min.

Weight and Dimensions

dimensions (H x W x D) not reclined with legrest lowered	41 11/32 x 34 41/64 x 40 35/64 in. (1050 x 880 x 1030 mm)
dimensions (H x W x D) reclined with legrest extended	29 9/64 x 34 41/64 x 68 7/64 in. (740 x 880 x 1730 mm)
reclining angle	Approx. 123° to 160°
weight	121 lbs. (55 kg)
maximum user weight	264 lbs. (120 kg)
