Panasonic EP1015 User Manual

15
BACK CUSHION AND HEADREST
CUSHION INSERT PAD
• Fasten the back cushion to the chair and the headrest and insert the weighted flap through the strap
attached behind the chair.
• If you prefer a stronger massage, remove the back cushion.
• When the massage function will be used, remove the headrest or flip the headrest over the back of the chair
before starting the massage.
NOTE:
• This massage lounger is capable of providing a vigorous “shiatsu” massage. The rolling and tapping action
are very strong, and this type of massage may be too strong for people who have not previously experi-
enced a shiatsu massage. For this reason, a foam cushion insert pad is provided to soften the effect of the
massage.
• The cushion insert pad can be removed for a full shiatsu massage, but be aware of the intensity of the
massage you will receive. The first time you try it – if you decide to – sit in a relaxed manner and do not use
it for more than two minutes. After that you should be able to decide whether or not you prefer a massage
with the pad in place.
• This pad is placed underneath the back cushion at the waist position for supporting the back and the waist,
and for overall chair comfort.
• Remove if unwanted during a massage.
Headrest
Back cushion
Weighted flap
Strap
Back cushion
Cushion insert pad

Panasonic EP1015 Specifications

Power

power source	120 V AC, 60 Hz
power consumption	200 W

Massage Specifications

kneading speed	Approx. 28 times/min.
tapping speed	Approx. 500 times/min. (per side)
rolling massage speed	Approx. 1 cycle every 37 sec.
massage width	Shoulder / lower back section: Approx. 2 15/16 in. (75 mm)
back rolling width/tapping width	Narrow: Approx. 3 5/16 in. (85 mm), Wide: Approx. 4 5/16 in. (110 mm)
massage heads up/down travel	Approx. 23 5/8 in. (600 mm)
regional back rolling	Automatic repetition within approx. 4 3/4 in. (120 mm) range
intensity adjustment	Adjusts massage head protrusion steplessly within approx. 1 3/4 in. (45 mm) range
shoulder position adjustment	5 steps
automatic shut-off	Approx. 15 min.

Weight and Dimensions

dimensions (H x W x D) not reclined with legrest lowered	41 11/32 x 34 41/64 x 40 35/64 in. (1050 x 880 x 1030 mm)
dimensions (H x W x D) reclined with legrest extended	29 9/64 x 34 41/64 x 68 7/64 in. (740 x 880 x 1730 mm)
reclining angle	Approx. 123° to 160°
weight	121 lbs. (55 kg)
maximum user weight	264 lbs. (120 kg)
