Panasonic EP1015 User Manual

9
RECLINING THE CHAIR
HOW TO EXTEND THE LEGREST MANUALLY
By using the reclining button on the controller, the legrest can be raised and lowered automatically in concert
with the movement of the massage lounger’s backrest.
• To avoid possible tipping of the chair, do not sit or lean on the backrest while chair back is in a reclined
position.
• The angle of the chair back can be changed so that the body weight and the massage heads will work
together to determine the strength of the massage.
• Try changing the angle of the chair back to find a comfortable massage of a strength that is most suitable for
you. The more you recline, the more intense the massage will feel. Adding or removing the cushion insert
pad will also increase the intensity.
NOTE:
Position the chair at least 16 in. (40 cm) away from any wall or other obstacle to ensure adequate reclining space.
To extend: Press and hold the button.
• While the button is pressed and held, the
legrest will extend and the backrest will
recline.
• Release the button when the desired position
has been reached.
To lower: Press and hold the button.
• The legrest will be returned to its resting position and the backrest will be raised.
• To obtain the maximum benefit from the massage, let your body relax and recline in a comfortable manner.
NOTE:
After use, always be sure to return the legrest and backrest to their resting positions (legrest lowered and
backrest raised).
By using the legrest lever on the side of the massage lounger, the legrest can be raised and lowered
independently from the chair back.
To extend: Pull the lever back.
• Pull the lever back as far as it will go (until
the lock catches).
• The legrest can be raised to 90°.
To lower: Push forward on the lever.
• When extending or lowering the legrest, lift
your legs off of the legrest and operate the
lever.
• The legrest cannot be lowered completely
if the massage lounger’s backrest is not
raised completely. (The same condition
occurs for lever operation.)
• The legrest will be locked in position when
it is raised using the legrest lever;
therefore, the legrest cannot be lowered
using the reclining button on the controller.
Always use the legrest lever to lower the
legrest if it has been raised by the legrest lever.
NOTE:
• When lowering the legrest, keep children and pets away from the massage lounger to prevent injury.
• Be aware that during powered reclining the legrest lever will move automatically.
on
off
on
off
quick
stop
reclining
1
3
5
neck
roller
position
Programmed Operation
160°
123°
85°
Can be raised to 90° by
using the legrest lever
Legrest lever

Panasonic EP1015 Specifications

Power

power source	120 V AC, 60 Hz
power consumption	200 W

Massage Specifications

kneading speed	Approx. 28 times/min.
tapping speed	Approx. 500 times/min. (per side)
rolling massage speed	Approx. 1 cycle every 37 sec.
massage width	Shoulder / lower back section: Approx. 2 15/16 in. (75 mm)
back rolling width/tapping width	Narrow: Approx. 3 5/16 in. (85 mm), Wide: Approx. 4 5/16 in. (110 mm)
massage heads up/down travel	Approx. 23 5/8 in. (600 mm)
regional back rolling	Automatic repetition within approx. 4 3/4 in. (120 mm) range
intensity adjustment	Adjusts massage head protrusion steplessly within approx. 1 3/4 in. (45 mm) range
shoulder position adjustment	5 steps
automatic shut-off	Approx. 15 min.

Weight and Dimensions

dimensions (H x W x D) not reclined with legrest lowered	41 11/32 x 34 41/64 x 40 35/64 in. (1050 x 880 x 1030 mm)
dimensions (H x W x D) reclined with legrest extended	29 9/64 x 34 41/64 x 68 7/64 in. (740 x 880 x 1730 mm)
reclining angle	Approx. 123° to 160°
weight	121 lbs. (55 kg)
maximum user weight	264 lbs. (120 kg)
